BD680
| Parameter | Value |
|---|---|
| Mounting | Through-Hole |
| Case | TO-126 |
| Configuration/ | PNP Darlington |
| Polarity | PNP |
| IC(max) | 4A |
| PD(max) | 40W |
| VCEO(max) | 80V |
| VCES(max) | - |
| hFE(min) | 750 |
| hFE(max) | - |
| @VCE | 3V |
| @IC | 1.5A |
| VCE(SAT)(max) | 2.5V |
| @IB | 6mA |
| Cob(TYP)in pF | - |
| Cob(max) in pF | - |
| fT(TYP)in MHz | - |
