CAF-A225B-120-350
| Parameter | Value |
|---|---|
| Bearing Type | Ball |
| Air Flow at 50Hz (CFM) | 51.94 |
| Air Flow at 60Hz (CFM) | 53.87 |
| Rated Speed at 50Hz (RPM) | 2000 |
| Rated Speed at 60Hz (RPM) | 2000 |
| Noise at 50Hz (dBA) | 36.4 |
| Noise at 60Hz (dBA) | 37.3 |
| Rated Voltage (Vac) | 110 |
| Rated Power at 60Hz (W) | 10.8 |
| Rated Power at 50Hz (W) | 14.2 |
| Max Input Current (mA) | 190 |
| Tachometer Signal | No |
| Rotation Detector | No |
| PWM Control Signal | No |
| Length (mm) | 120 |
| Width (mm) | 120 |
| Height (mm) | 25 |
