SWH24-15-N
The SWH24-15-N is a 24W isolated DC-DC converter from CUI Inc., featuring a 9-36VDC input and a 15VDC output at 1.6A. It offers 1600VDC isolation and comes in a compact 1" x 1" through-hole package.
Manufacturer:
CUI (Bel Fuse)Category:
Power Modules & Supplies
Sub Category:
AC-DC Wall Adapters
Datasheet
SWH24-15-N Datasheet
Product Description
The SWH24-15-N, manufactured by CUI Inc., is a robust 24W isolated DC-DC converter designed for a wide range of applications. Supreme Components International is an authorised distributor of CUI Inc. products. This converter accepts a 9-36VDC input and provides a regulated 15VDC output at 1.6A. It features 1600VDC isolation, ensuring safety and preventing ground loops in sensitive circuits. The compact 1" x 1" through-hole package allows for easy integration into existing designs. Ideal for industrial, telecommunications, and instrumentation applications where isolation and reliable power conversion are critical. Benefit from CUI Inc.'s quality and Supreme Components International's reliable distribution.
Technical Specifications
| Attribute | Description |
|---|---|
| Features | Remote On/Off, Over Current Protection, Over Voltage Protection, Short Circuit Protection, Under Voltage Lockout |
| Efficiency | 90% (Typical) |
| Power Rating | 24 Watts |
| Mounting Type | Through Hole |
| Converter Type | Isolated DC-DC |
| Isolation Type | Basic |
| Output Current | 1.6 Amperes |
| Output Voltage | 15 Volts DC |
| Line Regulation | Plus or Minus 0.2% (Maximum) |
| Load Regulation | Plus or Minus 0.5% (Maximum) |
| Regulation Type | Regulated |
| Ripple And Noise | 75 mVp-p (Typical) |
| Isolation Voltage | 1600 Volts DC |
| Number Of Outputs | 1 |
| Package Dimensions | 25.4 x 25.4 x 10.16 millimeters (1 inch x 1 inch x 0.4 inch) |
| Input Voltage Range | 9 to 36 Volts DC |
| Operating Temperature Range | -40 to +105 Degrees Celsius |
Ordering Information
| Attribute | Description |
|---|---|
| MPQ | 1 |
| WEIGHT | 13.5 g |
| Packaging Type | Tray |
